Overview

A709 CARBON STEEL COIL

ASTM A709 Steel Coil is in accordance with the standard specification for bridge structural steel. ASTM A709 Steel Coil is a carbon, high strength low alloy and quenched and tempered alloy steel mainly used for bridge construction. Kyushu Metal offers the following 5 grades of steel coils: A709, 36, 50, 50W, HPS 50W. The atmospheric corrosion resistance index of the three grades of 50W, HPS 50W and HPS 70W is 6.0.

ASTM A709 Gr.36/Gr.50/Gr.50W is used for steel structures/steel processing parts for bridges, railways, ships, vehicles, machine tools, etc. ASTM A709 Gr.36/Gr.50/Gr.50W steel includes carbon steel and high strength low alloy steel structural profiles, plates and bars and quenched and tempered alloy steel for structural plates.

Chemical composition
A709	50W			50	36
A709	Type A	Type B	Type C	50	≤20mm	20-40mm	40-65mm	65-100mm
C	0.19	0.2	0.15	0.23	0.25	0.25	0.25	0.27
Mn	0.80-1.25	0.75-1.35	0.80-1.35	1.35	-	0.80-1.20	0.80-1.20	0.80-1.20
P.max	0.04	0.04	0.04	0.04	0.04	0.04	0.04	0.04
S.max	0.05	0.05	0.05	0.05	0.05	0.05	0.05	0.05
Si.max	0.30-0.65	0.30-0.65	0.15-0.40	-	0.4	0.4	0.15-0.40	0.15-0.40
Cu.min	0.25-0.40	0.20-0.40	0.20-0.50	-	0.2	0.2	0.2	0.2
Ni.max	0.4	0.5	0.25-0.50	-	-	-	-	-
Cr	0.40-0.65	0.40-0.70	0.30-0.50	-	-	-	-	-
V	0.02-0.10	0.01-0.10	0.01-0.10	-	-	-	-	-
