COLD-ROLLED HIGH MAGNETIC INDUCTION ORIENTED SILICON STEEL

High magnetic induction and low iron loss cold-rolled oriented silicon steel sheets are urgently needed by the power industry. The higher the magnetic properties of silicon steel sheets, the better the electrical appliances manufactured: less power loss, smaller size, lighter weight, longer life, and less oil used for cooling the transformers manufactured. In particular, it can solve the problem that large electrical appliances such as transformers greater than 360,000 KVA cannot pass through railway tunnels and highway bridges when manufactured and transported with oriented silicon steel sheets with lower magnetic properties.


CategorySilicon content/%Nominal thickness/mm
Hot rolled silicon steel
(non-oriented)
Hot  rolled low silicon steel (motor steel)1.0~2.50.5
Hot rolled high silicon steel (transformer steel)3.0~4.50.35、0.50
Cold rolled electrical steelCold rolled non-oriented electrical steel (motor steel)Low carbon electrical steel≤0.50.50、0.65
Silicon Steel>0.5~3.50.35、0.50
Cold rolled oriented silicon steel (transformer  steel)Ordinary  oriented silicon steel2.9~3.30.18、0.23、0.27、0.30、0.35
High magnetic induction oriented silicon steel
Silicon steel for special purposeCold rolled oriented silicon steel strip2.9~3.30.03、0.05、0.10
Cold rolled non-oriented silicon steel strip30.15、0.20
Cold rolled non-oriented silicon steel for magnetic   switches30.7
Cold rolled high silicon steel6.50.1~0.5
