Overview

7075 ALUMINUM PLATE

7075 aluminum plate is a cold-treated forged alloy with high strength and hardness, far superior to mild steel. 7075 aluminum plate is one of the strongest commercial alloys, with general corrosion resistance, good mechanical properties and anodic reaction. Fine grains make deep drilling performance better, tool wear resistance enhanced, thread rolling more unique, and the preferred metal material when density requirements are small and hardness requirements are relatively high.

PRODUCT USE

It is used to manufacture aircraft structures and other high-stress structural parts that require high strength and strong corrosion resistance, such as upper and lower wing panels, trusses, bulkheads, etc. After solution treatment, it has good plasticity and particularly good heat treatment strengthening effect. It has high strength below 150℃ and particularly good low-temperature strength. It has poor welding performance and a tendency to stress corrosion cracking. Double-stage aging can improve SCC resistance. Provided by Wuxi Hanshin Metallurgy.

Alloy	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Others: Each	Others: Total	Al: Min.
1050	0.25	0.4	0.05	0.05	0.05	-	0.05	0.03	0.03	-	99.5
1060	0.25	0.35	0.05	0.03	0.03	-	0.05	0.03	0.03	-	99.6
1070	0.2	0.25	0.04	0.03	0.03	-	0.04	0.03	0.05	-	99.7
1100	0.95 Si + Fe		0.05~0.20	0.05	-	-	0.1	-	0.05	0.15	99
2014	0.5~1.2	0.7	3.9~5.0	0.4~1.2	0.2~0.8	0.1	0.25	0.15	0.05	0.15	margin
2017	0.2~0.8	0.7	3.5~4.5	0.4~1.0	0.4~0.8	0.1	0.25	0.15	0.05	0.15	91.5- 95.5
2024	0.5	0.5	3.8~4.9	0.3~0.9	1.2~1.8	0.1	0.25	0.15	0.05	0.15	margin
3003	0.6	0.7	0.05~0.20	1.0~1.5	-	-	0.1	-	0.05	0.15	margin
3A21	0.6	0.7	0.2	1.0-1.6	0.05	-	0.15	0.1-0.2	-	-	margin
3004	0.3	0.7	0.25	1.0~1.5	0.8~1.3	-	0.25	-	0.05	0.15	margin
3005	0.6	0.7	0.3	1.0~1.5	0.2~0.6	0.1	0.25	0.1	0.05	0.15	margin
3105	0.6	0.7	0.3	0.3~0.8	0.2~0.8	0.2	0.4	0.1	0.05	0.15	margin
5005	0.3	0.7	0.2	0.2	0.5~1.1	0.1	0.25	-	0.05	0.15	margin
5052	0.25	0.4	0.1	0.1	2.2~2.8	0.15~0.35	0.1	-	0.05	0.15	margin
5754	0.4	0.4	0.1	0.5	2.6~3.6	0.3	0.2	0.15	0.05	0.15	margin
5A05	0.5	0.5	0.1	0.3-0.6	4.8-5.5	-	0.2	-	0.05	0.05	margin
5083	0.4	0.4	0.1	0.4~1.0	4.0~4.9	0.05~0.25	0.25	0.15	0.05	0.15	margin
6061	0.40~0.8	0.7	0.15~0.4	0.15	0.8~1.2	0.04~0.35	0.25	0.15	0.05	0.15	margin
6082	0.70~1.3	0.5	0.1	0.4~1.0	0.6~1.2	0.25	0.2	0.1	0.05	0.15	margin
7075	0.4	0.5	1.2~2.0	0.3	2.1~2.9	0.18~0.28	5.1~6.1	0.2	0.05	0.15	margin
