Non-oriented silicon steel
Location:

Overview

HOT-ROLLED ELECTRICAL STEEL

The silicon content of low silicon sheets is less than 2.8%, and they have a certain mechanical strength. They are mainly used to manufacture motors, commonly known as motor silicon steel sheets.

It is an important soft magnetic alloy that is indispensable to the power, electronics and military industries. It is also the largest metal functional material. It is mainly used as the iron core of various motors, generators and transformers. Its production process is complex and the manufacturing technology is strict. Foreign production technologies are protected in the form of patents and are regarded as the life of the enterprise. The manufacturing technology and product quality of electrical steel sheets are one of the important indicators to measure the level of special steel production and scientific and technological development in a country.


CategorySilicon content/%Nominal thickness/mm
Hot rolled silicon steel
(non-oriented)
Hot rolled low silicon steel (motor steel)1.0~2.50.5
Hot rolled high silicon steel (transformer steel)3.0~4.50.35、0.50
Cold rolled electrical steelCold rolled non-oriented electrical steel (motor steel)Low carbon electrical steel≤0.50.50、0.65
Silicon Steel>0.5~3.50.35、0.50
Cold rolled oriented silicon steel (transformer steel)Ordinary oriented silicon steel2.9~3.30.18、0.23、0.27、0.30、0.35
High magnetic induction oriented silicon steel
Silicon steel for special purposeCold rolled oriented silicon steel strip2.9~3.30.03、0.05、0.10
Cold rolled non-oriented silicon steel strip30.15、0.20
Cold rolled non-oriented silicon steel for magnetic switches30.7
Cold rolled high silicon steel6.50.1~0.5
